This 90-ton class electric rigid dump truck is designed for open-pit mines, quarries, coal mines and fixed-route material haulage. With a 60T payload range, 350kWh CATL LFP battery, dual-motor 6×4 drive system and regenerative braking, NKE90D3 is especially suitable for downhill mining haulage where energy recovery, lower fuel cost and zero-emission operation are important.
This battery electric mining haul truck is built for heavy-duty off-highway transport. It combines the strong structure of a rigid dump truck with a full-electric powertrain, helping mining operators reduce diesel consumption, lower routine maintenance and improve fleet sustainability.
For mining companies, EPC contractors and quarry operators, the key selection factors are not only battery capacity, but also payload, gradeability, charging time, road condition and operating cycle. This electric rigid dump truck provides a practical solution for mines looking to replace diesel haul trucks with zero-emission mining equipment.
| Item | NKE90D3 Parameter (350 kWh) | NKE90D3 Parameter (422 kWh) |
| Product specs | 350 kw charging / replacing Mode | 422 kw charging / replacing Mode |
| Best Working condition | Downhill | Downhill |
| Rated Power(kW/rpm) | 2×225 / 2×300 | 2×225 / 2×300 |
| Max.Torque (Nm/rpm) | 2×460 / 2×700 | 2×460 / 2×700 |
| Capacity(kwh) | 350 | 422 |
| Size(mm) | 9460×3600×4100 | 9460×3600×4100 |
| Drive model | 6×4 | 6×4 |
| Buggy Capacity (m³) | 33 (Standard loading) 36 (Pile loading) | 33 (Standard loading) 36 (Pile loading) |
| Tyre | Radial Tyre | Radial Tyre |
| Max.Speed(km/h) | 43 | 43 |
| Gradeability (%) | 35 | 35 |
| Min.Turning Radius (m) | 11.5 | 11.5 |
| Item | NKE90D3 Parameter (350 kWh) | NKE90D3 Parameter (422 kWh) |
| Gross Weight (kg) | 90000 | 90000 |
| Tare Weight(kg) | 34000 | 34000 |
| Payload (kg) | 60000 | 60000 |
| Axle Capacity Front / Mid / Rear (t) | 20+35+35 | 20+35+35 |
Note: The above data are standard product data.The data may change with product
improvement and configuration. The actual data is subject to the actual product .
This 90-ton class electric rigid dump truck is suitable for copper mines, iron ore mines, coal mines, limestone quarries and other open-pit mining sites. It is designed for high-frequency transport of ore, overburden, aggregates and bulk materials on fixed mine roads.
For projects with downhill loaded routes and uphill empty return routes, the regenerative braking system can help recover part of the braking energy. This makes the truck a strong choice for mining operations that want to reduce fuel cost, brake wear and on-site emissions.
The truck uses a 350kWh CATL lithium iron phosphate battery system. LFP battery technology is widely used in heavy-duty electric equipment because of its stability, safety and long service life.
For mine operators, battery capacity directly affects route planning, charging frequency and daily operating efficiency. The 350kWh battery configuration is suitable for medium-distance haul roads, downhill operating conditions and shift-based mine transport.
The two-gun fast charging system helps reduce downtime and supports higher vehicle utilization during continuous mining operations.
A dual-motor 6×4 electric drive system provides strong torque output for mine roads, ramps and heavy-load transport. Compared with traditional diesel powertrains, the electric drivetrain offers faster response, smoother acceleration and better control in low-speed heavy-duty conditions.
With up to 35% gradeability, this electric mining haul truck can meet the transport requirements of many open-pit mines and quarry roads. It is suitable for customers who need both payload capacity and practical climbing performance.
In mining haulage, braking and energy consumption have a direct impact on operating cost. The regenerative braking system allows the vehicle to recover part of the energy during downhill driving, deceleration and braking.
This is especially useful for downhill mining haulage. It can help reduce total power consumption, lower brake system wear and improve the economics of battery electric mining truck operation.
This electric rigid dump truck is built for demanding off-highway conditions. The rigid frame, heavy-duty suspension, mining-grade body and durable electric components are designed to handle impact, vibration, dust and rough mine roads.
The cab layout, steering system, cooling system and maintenance access are designed for practical mine-site operation. For fleet owners, the goal is not only to purchase an electric dump truck, but to keep the vehicle working reliably across multiple shifts.
This 90-ton class electric rigid dump truck is suitable for:
Open-pit coal mine haulage
Copper mine and iron ore mine transport
Limestone quarry operations
Downhill mining haul roads
Short- to medium-distance ore transport
Overburden and aggregate haulage
Mining contractors replacing diesel dump trucks
Zero-emission mining fleet pilot projects
This model is recommended if your project requires:
A 90-ton class electric rigid dump truck
60–70T payload capacity
350kWh battery configuration
Downhill or fixed-route mining haulage
Fast charging instead of long charging downtime
Lower fuel cost compared with diesel trucks
Zero-emission operation for open-pit mines or quarries
If your mine requires longer endurance, larger payload or uphill-heavy operation, we can help compare different electric mining haul truck models based on haul distance, road slope, loading cycle and charging conditions.
KNOWHOW CASES:
Electric coal mine trucks in Brazil
Different types of mining trucks
Mining dump trucks in Mongolia
Key advantages include:
60–70T payload for mining haulage
350kWh CATL LFP battery system
Dual-motor 6×4 electric drive
35% gradeability for mine roads
Regenerative braking for downhill haulage
Two-gun fast charging
Zero tailpipe emissions
Lower maintenance than diesel powertrains
Suitable for open-pit mines, quarries and off-highway transport
When choosing an electric mining truck, buyers should compare more than battery capacity. The right model depends on payload, haul distance, road slope, charging time, operating shifts, road surface and mine layout.
For this 90-ton class electric rigid dump truck, the most suitable working conditions are:
Payload demand around 60–70T
Downhill or mixed-grade haul roads
Medium-distance transport routes
Fixed mine or quarry operation routes
Sites with fast-charging infrastructure
Mines looking to reduce diesel consumption
Projects requiring zero-emission mining transport
KNOW-HOW full-electric mining NKE90D3 90-Ton Class Electric Rigid Dump Truck aims to create four core advantages of being safe, reliable, efficient and economical.
The electronic control technology of KNOW-HOW has won the second prize of National Science and Technology Progress Award.
We use EV system with triple protections (protections against water, fire and electronic shock). We adopt design of high standard ("3S Safety Technology Requirements for New Energy truck") to make it safer.
With diamond-enclosed-ring structure, the cab can be of high safety.
Frame: We use box-shaped welded rigid frame for strong impact resistance and longer use of the chassis and auto parts.
Leaf spring suspension: The overall matching strngth is high and the single piece of leaf spring is thick and strong, which can lower the failure rate and maintenance costs.
Hydro pneumatic suspension: It has great buffering and damping ability which is suitable for the complex road conditions in the mining area with low maintenance cost and high usage rate.
Drive moto: It uses anti-condensation structure of KNOW-HOW to ensure the long-term reliable operation of tippers in bad weather. It can reduce the maintenance, improve reliability and save use costs.
Integrated moto controller: With high level of integration and a few high-voltage connection points, it has redundant power supply to ensure the reliability.
EV system protection: The level of EV system protection is IP68+IP6K9K. It functions well after jetting by the hydraulic giant of high temperature and high pressure, which has achieved the top level around the world.
The 90-Ton Class Electric Rigid Dump Truck has a large volume so that a single transportation is highly-efficient, which gurantees greater benefits. The warranty period of the tipper's core components is long and the EV system is stable. So the tipper can be used frequently.
The 90-Ton Class Electric Rigid Dump Truck has a large volume so that a single transportation is highly-efficient, which gurantees greater benefits. The warranty period of the tipper's core components is long and the EV system is stable. So the tipper can be used frequently.
Steering: The steering system (ball stud) uses the biggest taper pin or cotter pin in the industry. It's reliable and has long service life.
Cab: The cab can be turned over which is convenient for maintenance.
Radiator: The cab can be turned over which is convenient for maintenance. The radiator area is large and it has strong climate adaptability. The radiator is detachable for low maintenance cost.
The maximum efficiency of the high-efficient motor system (motor and motor controller) is equal to or greater than 96％, which plays a leading role in the industry.
uses the improved regenerative braking energy recovery design. When the tipper is coasting or braking, the drive moto works as the generator to generate electric for battery charging, which achieves the braking energy recovery.
Looking for a 90-ton class electric rigid dump truck for your mining project? Contact us to get NKE90D3 specifications, working condition matching and electric mining truck quotation.
A 90-ton class electric rigid dump truck is a battery electric off-highway mining truck designed for heavy-duty haulage in mines and quarries. It is commonly used for transporting ore, overburden, aggregates and bulk materials on mine roads.
This model is designed for 60–70T payload requirements, depending on the working condition and configuration.
Yes. It is suitable for open-pit mines, coal mines, metal mines, limestone quarries and other fixed-route haulage applications.
The truck is equipped with a 350kWh CATL LFP battery system, suitable for heavy-duty mining and off-highway transport.
It is especially suitable for downhill mining haulage, where regenerative braking can help recover energy and reduce operating cost.
With two-gun fast charging, the battery can be charged from approximately 10% to 90% in about 40 minutes, depending on charging infrastructure and site conditions.
Both terms are suitable. For mining buyers, “electric rigid dump truck” emphasizes the vehicle structure, while “electric mining haul truck” emphasizes the application and transport function.
Yes. For suitable mine routes and charging conditions, this battery electric mining truck can help reduce diesel fuel use, tailpipe emissions and powertrain maintenance.
As the cost of fossil fuels soars, the electric tipper is set to be a game-changer in the field. Since then, KNOWHOW has been testing electric tipper under different geographical conditions in the country and developed 60ton/70ton electric tipper, which is the first choice product for the mining industry
60ton load capacity
Featuring a zero-emission drivetrain that delivers sustainability and real-world performance
The maximum slope can reach 35%, ranking among the best
Completely made in China
Off-road electric tipper for difficult dirt or sandy terrain
Industry-leading electric tipper-KNOWHOW electric tipper
Weight when fully loaded is 60 tons
(GVM) can be configured to 90,000 kg
Combines the positive attributes of all-electric while also delivering the performance and towing capabilities required in the real world
Reduce upfront and opex costs
Battery capacity 350-422 kWh
Dump trucks are often used in mining industries that have traditionally been powered by diesel engines.
Maximum torque 1400 Nm
6X4 axle configuration
Powertrain: Sturdy powertrain, noiseless operation
Fast charging technology: high-power DC charging 1 hour to charge, 5 mins to replace
Battery: Lithium iron phosphate (LFP) battery
Extended range on a single charge up to 120 – 150 kilometers
Long service life with minimal maintenance
100% emission-free
